  Skid steer loader
  Skid-Steer Loader，Designed for Efficient Operation in Tight Spaces
  View All
  CM-S16 Skid Steer Loader
  Rated load capacity (kg)
  745
  Total weight (kg)
  2620
  Payload (tons)
  Less than 0.8 tons
  Rated power (kW/rpm)
  36.5
  Maximum speed (km/h)
  10.5
  Unloading distance (at maximum height) (mm)
  457
  Maximum height of the bucket hinge pin (mm)
  2918
  Overall length (with bucket) (mm)
  3375
  Overall width (bucket edge) (mm)
  1728
  Overall height (to the top of the cab) (mm)
  1999
  Minimum ground clearance (mm)
  186
  More parameters
  CM-260 Tracked Skid Steer Loader
  Power Mode
  Crawler-type
  Rated load capacity (kg)
  260
  Overturning load (kg)
  730
  Total weight (kg)
  1500
  Types of Lifting Mechanisms
  Radial lifting
  Engine Brand
  CatKubotaWeichaiYuchaiYunnei
  Rated power (kW/rpm)
  25.1/2800
  Maximum torque (N·m)
  87
  Engine displacement (L)
  1.5
  Emissions Standards
  U.S.EPA Tier 3
  Maximum speed (km/h)
  9.4
  Bearing pressure (kPa)
  19.2
  Track plate width (mm)
  297
  Angle of departure (°)
  55
  System pressure (bar)
  207
  System Rated Flow Rate (L/min)
  37.9
  Fuel Tank (L)
  37.9
  Crankcase (L)
  3.8
  Engine Coolant (L)
  5.6
  Hydraulic Oil Tank (L)
  30.3
  Maximum height of the bucket hinge pin (mm)
  2038
  Overall length (with bucket) (mm)
  2845
  Total length (without attachments) (mm)
  2311
  Overall width (track edge to edge) (mm)
  1220
  Overall height (to the top of the cab) (mm)
  1805
  Minimum ground clearance (mm)
  255
  Track contact length (mm)
  1380
  More parameters
  Compact excavator
  Compact Excavators The Ideal Choice for Small-Scale Projects
  View All
  CM-Y06 Compact Excavator
  Bucket capacity (m³)
  0.02
  Bucket digging force
  7.5kn
  Maximum climbing angle
  30°
  Engine Model
  Air-cooled single-cylinder diesel engine
  Maximum engine output
  7.6 kW / 8.2 kW
  Walking speed
  1.8 km/h
  Dimensions (L x W x H)
  2480 x 720 x 1375 mm
  Total weight
  600 kg
  Track length
  1140 mm
  Track width
  150 mm
  Minimum ground clearance
  80 mm
  Maximum digging height
  2350 mm
  Maximum unloading height
  1600 mm
  Maximum digging depth
  1200 mm
  Maximum digging radius
  2450 mm
  Minimum turning radius
  1100 mm
  Maximum ground clearance of the dozer blade
  120 mm
  Maximum depth of blade penetration
  200 mm
  More parameters
  Lawn mower
  Track-Type Lawn Mower Essential Equipment for Weed and Lawn Maintenance
  View All
  CM-S750 Tracked Transport Vehicle
  Dimensions (L x W x H)
  1.8 x 0.75 x 1.2 m
  Container dimensions
  1.20*0.75*0.45m
  Wheelbase
  70 cm
  Engine Make and Model
  186FA
  Transmission Material and Model
  Guli Model 13
  Track Specifications and Models
  180*72*38mm
  Track type
  Steel-cord rubber tracks
  Hydraulic dump function
  Yes
  Can a crane be added?
  Yes
  Startup method
  Electric/Manual
  Load capacity
  650 kg
  gear
  3 forward gears, 1 reverse gear
  Ground clearance
  42 cm
  Ascent angle
  ≤45°
  More parameters
  BCW5687 Pro
  Rated load
  0.8 Tons0.5 Tons0.3 Tons0.2 Tons
  Power Mode
  Wheeled
  Engine Brand
  CatWeichai
  Remote-controlled lawn mower
  Track-Type Lawn Mower Essential Equipment for Weed and Lawn Maintenance
  View All
  CM-G530 Remote-Control Lawn Mower
  Overall dimensions
  1000*880*550mm
  Charging Mode
  Self-charging system
  Cutting width
  530mm
  Stubble height
  20mm-120mm
  Speed
  0-7km/H
  Climbing angle
  ＜45°
  Total weight
  145kg
  Working Method
  Hybrid
  Startup method
  Electric start / Recoil start
  How to Use
  Remote control
  Travel motor
  2 x 600W motors
  Battery model
  24v12A
  Engine
  Gasoline engine
  Output power
  9HP
  More parameters
  OPO5684 PA Mini Workstation
  Rated load
  0.8 Tons0.5 Tons0.3 Tons0.2 Tons
  Power Mode
  Wheeled
  Engine Brand
  CatWeichai
  Electric forklift
  All-Terrain Forklifts,Electric Forklifts,The Ultimate Solution for Outdoor and Indoor Material Handling
  View All
  OPO5684 PA Mini Workstation
  Rated load
  0.8 Tons0.5 Tons0.3 Tons0.2 Tons
  Power Mode
  Wheeled
  Engine Brand
  CatWeichai
  CM-CPD-15 1.5-Ton Electric Forklift
  Model
  CM-CPD-15
  Lifting height
  3000mm
  Net weight (including battery)
  2200kg
  Rated load capacity
  1500kg
  Driving Style
  Ride-on
  Drive Type
  Electric
  Drive Control Type
  AC Speed Control
  Wheelbase
  1350mm
  Tire Type
  Solid tire
  Number of wheels: front/rear (x = driven wheel)
  2x/2
  Front wheel track
  930mm
  Rear track width
  890mm
  Overall length
  3170mm
  Overall width
  1070/1220mm
  Vehicle length
  2100mm
  Fork dimensions
  35/100/1070
  Brake Type
  Hydraulic
  Drive motor power
  4.0kw
  Travel speed (fully loaded/unloaded)
  11/13(km/h)
  Gradeability (fully loaded/unloaded)
  12/15 (%)
  Hoist motor power
  3.0 kw
  Battery Voltage/Capacity
  60/70 (V/An)
  More parameters
  CM-T300 Off-Road Forklift with Multi-Function Rear Crane
  Product Model
  CM-T300
  Equipment Load
  3-ton 4WD off-road forklift with rear crane
  Equipment Name
  3M x 4-section manganese steel arm
  Engine Model/Power
  Yunnei 490/55 kW
  Drive Type
  Sigang
  support leg
  5 legs
  Rated capacity of the boom
  3 tons
  Forklift lifting capacity
  3.5 tons
  Operation Mode
  Perform the operation
  Fork length
  1220mm
  Boom rotation angle
  360°
  Lifting height
  4000mm
  Tire Size
  20.5/70-16
  Braking system
  All-wheel wet brakes
  Axle
  Heavy-duty truck axle
  Transmission type
  Continuously variable transmission
  Hill-climbing ability
  30°
  More parameters
  CM-T500 Off-Road Forklift with Multi-Function Rear Crane
  Product Model
  CM-T500
  Product Name
  5-ton 4WD off-road forklift with rear crane
  Boom Specifications
  4M x 4-section manganese steel arm (custom)
  Engine Model/Power
  4102 Turbocharged / 76 kW
  Rated capacity of the boom
  5.0 Tons
  Drive Type
  All-wheel drive
  support leg
  5 legs
  Forklift lifting capacity
  5.0 Tons
  Operation Mode
  Operations on the equipment
  Fork length
  1520mm
  Boom rotation angle
  360°
  Lifting height
  6000mm
  Tire Size
  16/70-20
  Braking system
  All-wheel wet brakes
  Axle
  Heavy-duty large-flange girder bridge
  Transmission type
  Continuously variable transmission
  Hill-climbing ability
  35°
  More parameters
  BCW5687 Pro
  Rated load
  0.8 Tons0.5 Tons0.3 Tons0.2 Tons
  Power Mode
  Wheeled
  Engine Brand
  CatWeichai
  Concrete mixer truck
  Concrete Mixer Truck Designed for concrete road transport, offering stability and high efficiency
  View All
  CM-260 Tracked Skid Steer Loader
  Power Mode
  Crawler-type
  Rated load capacity (kg)
  260
  Overturning load (kg)
  730
  Total weight (kg)
  1500
  Types of Lifting Mechanisms
  Radial lifting
  Engine Brand
  CatKubotaWeichaiYuchaiYunnei
  Rated power (kW/rpm)
  25.1/2800
  Maximum torque (N·m)
  87
  Engine displacement (L)
  1.5
  Emissions Standards
  U.S.EPA Tier 3
  Maximum speed (km/h)
  9.4
  Bearing pressure (kPa)
  19.2
  Track plate width (mm)
  297
  Angle of departure (°)
  55
  System pressure (bar)
  207
  System Rated Flow Rate (L/min)
  37.9
  Fuel Tank (L)
  37.9
  Crankcase (L)
  3.8
  Engine Coolant (L)
  5.6
  Hydraulic Oil Tank (L)
  30.3
  Maximum height of the bucket hinge pin (mm)
  2038
  Overall length (with bucket) (mm)
  2845
  Total length (without attachments) (mm)
  2311
  Overall width (track edge to edge) (mm)
  1220
  Overall height (to the top of the cab) (mm)
  1805
  Minimum ground clearance (mm)
  255
  Track contact length (mm)
  1380
  More parameters
